Product Description
|
Type |
PERC |
|
Panel Efficiency |
21.9% |
|
Cable&Connector |
4mm²,EVO2 or EVO2 Compatible |
|
Front Glass |
2.0 mm (0.08 inches), High Transmission AR Coated Heat Strengthened Glass |
|
Back Glass |
2.0 mm (0.08 inches), Heat Strengthened Glass (White Grid Glass) |
|
Panel Size |
2384±2mmx1096±2mm×35/30mm |
|
Solar Cell Size |
Mono 210*210mm |
|
No. of Cells |
132(6×22） |
|
Weight |
38.7kg±3% |
|
Warranty |
30years |
|
Certificate |
TUV,CE,IEC,INMERTO,ISO |
|
Application Class |
Class A |
|
Frame |
Anodized Aluminium Alloy |
|
Junction Box |
IP68 ,3Diodes |
|
Modules Per Pallet |
31/36pieces |
|
Modules Per 40HQ |
570/670pieces |
Product Advantages
- High Efficiency: The Jingsun 670W Solar Panel is highly efficient and can convert up to 21.9% of the energy from the sun into electricity. This makes it one of the most efficient solar panels on the market today.
- Durability: Jingsun 670W Solar Panel is made with high-quality materials that make it durable and long-lasting. It can withstand harsh weather conditions, including extreme heat, cold, and rain.
- Easy Installation: The Solar Panel is easy to install, and it comes with a detailed manual that makes the process even simpler. It can be installed on any roof, and the installation process takes very little time.
- Eco-Friendly: Using a Jingsun 670W Solar Panel is an environmentally friendly way to generate electricity. It is a renewable source of energy that does not emit any harmful greenhouse gases, making it a great choice for those who want to reduce their carbon footprint.
- Cost-Effective: While the initial cost of a Solar Panel may be higher than traditional electricity sources, it is a cost-effective choice in the long run. It generates electricity for free, and the savings on energy bills can add up over time. Additionally, many governments offer tax incentives for those who choose to install solar panels on their homes or businesses, making the investment even more cost-effective.
Electrical Parameters at STC
|
Maximum Power (Pmax) |
670W |
|
Maximum Power Voltage (Vmp) |
38.2V |
|
Maximum Power Current (lmp) |
17.54A |
|
Open-Circuit Voltage (Voc) |
44.34V |
|
Short-Circuit Current (lsc) |
18.62A |
|
Power Tolerance |
0~+5W |
|
Temperature Coefficients of lsc |
+0.042%°C |
|
Temperature Coefficients of Voc |
-0.262%°C |
|
Temperature Coefficients of Pmax |
-0.362%°C |
|
STC (Standard Testing Conditions) |
lrradiance 1000W/㎡, Cell Temperature 25°C, Spectra at AW1.5G |
Electrical Parameters at NOCT
|
Maximum Power (Pmax) |
717W |
|
Maximum Power Voltage (Vmp) |
38.2V |
|
Maximum Power Current (lmp) |
18.77A |
|
Open-Circuit Voltage (Voc) |
44.34V |
|
Short-Circuit Current (lsc) |
19.74A |
|
Irradiance radio (rear/front) 10% |
Power Bifaciality: 70±10% |
|
Maximum System Voltage |
1000/1500V DC(IEC) |
|
Operating Temperature |
-40°℃-+85℃ |
|
Maximum Series Fuse |
30/35A |
|
Maximum Static Load,Front |
5400Pa, 1.5 |
|
Maximum Static Load,Back |
2400Pa, 1.5 |
|
NOCT(Nominal Operating Cel Temperature) |
45±2℃ Irradiance 800W/m², ambient temperature 20℃,wind speed 1m/s, AM1.5G |
Applications
Jingsun670W Solar Panel is a reliable choice for large-scale solar power generation stations. Its high efficiency, durability, and low maintenance make it ideal for use in harsh environments, and the panels can generate a significant amount of clean energy over their long lifespan.
For personal use, the Jingsun670W Solar Panel can be used to power homes and other buildings. It can help homeowners reduce their reliance on traditional energy sources, lower their electricity bills and reduce their carbon footprint. Plus, with its sleek and modern design, it can even enhance the aesthetic of a home.
FAQ
Q: What is the warranty for the Jingsun 670W Solar Panel?
Q: What is the size of the Jingsun 670W Solar Panel?
Q: What applications is the Jingsun 670W Solar Panel suitable for?
