Product Advantages
- High Power Output: The Jinko 570W solar panel boasts a high power output, offering up to 570 watts of energy per panel. This ensures maximum energy production, even in low light conditions.
- Advanced Cell Technology: These solar panels are equipped with advanced cell technology, including half-cut cells and multi-busbar design. This design enhances the panel's efficiency and durability, providing more power output and a longer lifespan.
- Durability: Jinko 570W solar panels are made from high-quality materials that can withstand harsh weather conditions and extreme temperatures. They are also designed to resist salt corrosion, making them ideal for coastal regions and other harsh environments.
- Improved Efficiency: The Jinko 570W solar panel is designed with a larger surface area, which allows for better sunlight absorption and improved energy production. Additionally, the panel's anti-reflective coating helps to minimize energy loss, further improving efficiency.
- Compatibility: Jinko 570W solar panels are designed to be compatible with a wide range of solar energy systems, including both commercial and residential setups. This makes them a versatile and reliable option for anyone looking to harness the power of the sun.
Specifications
Electrical Parameters At ST
|
TYPE |
JKM565N-72HL4 |
JKM570N-72HL4 |
JKM575N-72HL4 |
JKM580N-72HL4 |
JKM585N-72HL4 |
|
Rated Maximum Power(Pmax) |
565W |
570W |
575W |
580W |
585W |
|
Max Power Voltage(Vmp) |
41.92V |
42.07V |
42.22V |
42.37V |
42.59V |
|
Max Power Current(lmp) |
13.48A |
13.55A |
13.62A |
13.69A |
13.76A |
|
Open Circuit Voltage(Voc) |
50.60V |
50.74V |
50.88V |
51.02V |
51.16V |
|
Short Circuit Current(lsc) |
14.23A |
14.31A |
14.39A |
14.47A |
14.55A |
|
Module Efficiency |
21.87% |
22.07% |
22.26% |
22.45% |
22.65% |
|
Power Tolerance |
0~+5W |
||||
|
Temperature Coefficient of lsc(α_lsc) |
+0.048%/°C |
||||
|
Temperature Coefficient of Voc(β_Voc) |
-0.28%/°C |
||||
|
Temperature Coefficient of Pmax(γ_Pmp) |
-0.35%/°C |
||||
|
STC |
Irradiance 1000W/m²，cell temperature 25°C，AM1.5G |
||||
Electrical Parameters At NOCT
|
TYPE |
JKM565N-72HL4 |
JKM570N-72HL4 |
JKM575N-72HL4 |
JKM580N-72HL4 |
JKM585N-72HL4 |
|
Rated Maximum Power(Pmax) |
425W |
429W |
432W |
436W |
440W |
|
Max Power Voltage(Vmp) |
39.38V |
39.51V |
39.60V |
39.69V |
39.81V |
|
Max Power Current(lmp) |
10.79A |
10.85A |
10.92A |
10.99A |
11.05A |
|
Open Circuit Voltage(Voc) |
48.06V |
48.20V |
48.33V |
48.46V |
48.60V |
|
Short Circuit Current(lsc) |
11.49A |
11.55A |
11.62A |
11.68A |
11.75A |
Operating Conditions
|
Maximum System Voltage |
1000V/1500V DC(IEC) |
|
Operating Temperature |
-40°C~+85°C |
|
Maximum Series Fuse |
25A |
|
Maximum Static Load,Front |
5400Pa(112lb/ft²) |
|
Maximum Static Load,Back |
2400Pa(50Ib/ft²) |
|
NOCT |
45±2°C |
|
Safety Class |
Class II |
|
Fire Performance |
UL Type 1 |
Brand Cooperation
- Jingsun, a leading solar panel manufacturer, has formed strong partnerships with major solar energy companies. By collaborating with these industry leaders, Jingsun is able to provide customers with innovative and high-quality solar products that meet their needs and exceed their expectations.
- These strategic alliances enable Jingsun to stay at the forefront of solar technology advancements while simultaneously expanding its product portfolio.
- Through these close collaborations, Jingsun is able to leverage its expertise and resources to deliver reliable and cost-effective solar solutions. Customers benefit from the combined strengths of Jingsun and its partners, which include cutting-edge technology, industry knowledge and experience, and a commitment to excellence.
- Jingsun’s partnerships with major solar companies also provide a platform for developing new technologies and solutions that drive the industry forward. Jingsun remains dedicated to innovation and sustainability, and its collaborations with renowned solar companies reflect its unwavering commitment to delivering exceptional products that contribute to a cleaner and brighter tomorrow.
FAQ
Q: What is the efficiency of the Jinko 570W solar panel?
Q: What is the temperature coefficient of the Jinko 570W solar panel?
Q: What is the voltage and current output of the Jinko 570W solar panel?
Q: How durable and reliable is the Jinko 570W solar panel?
Q: How does the Jinko 570W solar panel compare to other solar panels on the market?
