Product Description
- Controller options: One of the biggest advantages of hybrid all-in-one solar inverters is the ability to choose different types of controllers, including MPPT and PWM. These controllers allow for maximum power point tracking and power optimization, helping to increase the efficiency of the system.
- Grid priority: Another significant advantage of hybrid all-in-one solar inverters is the ability to prioritize the grid. This means that in the event that solar power is not available, the system can switch over to grid power seamlessly. Additionally, when the grid is available, these inverters will work in conjunction with it to ensure that the batteries stay charged and ready to use.
- Energy-saving Mode: Hybrid all-in-one solar inverters also come equipped with an energy-saving mode. When this mode is enabled, the system will automatically adjust its output to match the power levels being used in the home or office. This helps to decrease energy consumption and increase the lifespan of the system.
- Ease Of Installation And Maintenance: Hybrid all-in-one solar inverters are relatively easy to install and maintain. They are designed to be all-inclusive, so there is no need to purchase separate components or equipment. Additionally, they are equipped with robust protection features that help to ensure the longevity of the system.
Products Specification
|
Rated Power |
1KW |
2KW |
3KW |
4KW |
5KW |
6KW |
|
|
Input Voltage |
12/24V |
12/24/48V |
24/48V |
48V |
|||
|
Input |
DC Input Range |
10.5-15VDC(Single battery voltage) |
|||||
|
AC Input Range |
85VAC~138VAC/89VAC~144VAC/93VAC~150VAC/ |
||||||
|
Frequency Input Range |
45Hz~65Hz |
||||||
|
Output |
Output Efficiency |
≥85% |
|||||
|
Output Voltage |
110VAC±2%/115VAC±2%/120VAC±2%/ |
||||||
|
Output Waveform |
Pure sine wave |
||||||
|
Solar Controller Build In (optional) |
Charging Mode |
PWM or MPPT |
|||||
|
Charging Current |
10A,20A,30A,40A,50A,60A |
||||||
|
PV Input Range |
12VSystem:15V-44V；12VSystem:30V-44V；12VSystem:60V-88V |
||||||
|
Max PV Voltage |
12V/24VSystem:50V；48VSystem:100V |
||||||
|
Working Mode |
Battery First/AC First/Saving Energy Mode |
||||||
|
AC Charging current（ selectable） |
0~30A |
||||||
|
Transfer Time |
≤4ms |
||||||
|
Battery Type(selectable) |
LEAD,OP-LE,LITHIUM |
||||||
|
Protection |
Over-load/Over-discharge/Short circuit/ |
||||||
|
Communication |
RS232/RS485（Optional） |
||||||
|
Net Size(L*W*Hmm) |
490*300*130 |
510*320*130 |
|||||
|
Packing Size(L*W*Hmm) |
565*395*225 |
510*320*130 |
|||||
Products Display
Hybrid All-in-one Machine 3.5kw Side
Hybrid All-in-one Machine 3.5kw Bottom Surface
Hybrid All-in-one Machine 5.5kw Side
Hybrid all-in-one machine 5.5KW
Hybrid All-in-one Machine 10kw Side
Hybrid All-in-one Machine 10kw Bottom Surface
Applications
The most common application for inverter hybrid off-grid systems is for residential use. Homeowners can install solar panels on their roofs to generate electricity during the day, which is then stored in batteries for use at night.
These systems can power a range of household appliances, including lights, fans, refrigerators, and even air conditioning units. By reducing reliance on traditional grid power, homeowners can save money on their energy bills and reduce their carbon footprint.
Inverter hybrid off-grid systems are also being used in industrial settings. Factories and other industrial facilities need a reliable source of power to keep production lines running smoothly. Inverter hybrid systems can be used to power machinery and equipment, reducing dependence on the grid and reducing energy costs. In some cases, these systems can also be used to offload excess energy back to the grid, creating additional revenue streams for industrial businesses.
FAQ
Q: What is a Hybrid All-in-One?
Q: How long is the service life of your inverter?
Q: What are the requirements for equipment installation?
