Product Advantages
1. High Module Efficiency - This solar panel boasts an impressive module efficiency of up to 21.2%. This means that it is capable of converting a significant percentage of the sun's energy into usable electricity. This high efficiency ensures that you get more power output from your solar panels, making it a cost-effective solution.
2. High-Density Interconnect Technology - The Trina 555W solar panel is equipped with high-density interconnect technology, which allows for better power output and reduces the overall size and weight of the panel. This technology offers a higher density of connections within each cell, which improves current collection and can save valuable space on your roof space or ground mount.
3. Multi-Busbar Technology - The multi-busbar technology used in the Trina 555W solar panel helps improve light trapping, lower series resistance, and increase current collection. This means that it can generate more power in low light conditions, making it an excellent solar panel for areas with limited sunlight.
4. Innovative Design - The Trina 555W solar panel is designed using advanced technology that ensures maximum durability, reliability, and performance. Its innovative design allows it to withstand harsh weather conditions and maintain efficiency over a long period of time, making it ideal for commercial and industrial applications.
5. Environmentally Friendly - In addition to being cost-effective and efficient, the Trina 555W solar panel is also an environmentally friendly solution for your energy needs. It helps reduce your carbon footprint by generating green energy from the sun, making it an excellent investment for those who are conscious about the environment.
Dimensions Of PV Module(mm)
Mechanical Data
|
Solar Cells |
Monocrystalline 210mm PERC |
|
No. of cells |
110cells |
|
Module Dimensions |
2384×1096×35 mm (93.86×43.15×1.38 in) |
|
Weight |
32.3kg (71.2 lb) |
|
Front Glass |
2.0 mm (0.08 in), High Transmission, AR Coated Heat Strengthened Glass |
|
Encapsulant material |
EVA/POE |
|
Back Glass |
2.0 mm (0.08 in), Heat Strengthened Glass (White Grid Glass) |
|
Frame |
35 mm (1.38 inches) Anodized Aluminium Alloy |
|
J-Box |
IP 68 rated |
|
Cables |
Photovoltaic Technology Cable 4.0mm2 (0.006 inches2), Portrait: N 450 mm/P 450 mm(17.72/17.72 inches) Landscape: N 1400 mm /P 1400 mm (55.12/55.12 inches) |
|
Connector |
MC4 EVO2/TS4 |
Electrical Data (STC)
|
Peak Power Watts-PMAX |
535Wp |
540Wp |
545Wp |
550Wp |
555Wp |
|
Power Tolerance-PMAX |
0 ~ +5W |
||||
|
Maximum Power Voltage-VMPP |
31.2V |
31.4V |
31.6V |
31.8V |
32.0V |
|
Maximum Power Current-IMPP |
17.16A |
17.21A |
17.24A |
17.29A |
17.35A |
|
Open Circuit Voltage-VOC |
37.5V |
37.7V |
37.9V |
38.1V |
38.3V |
|
Short Circuit Current-ISC |
18.24A |
18.30A |
18.35A |
18.39A |
18.43A |
|
Module E ciency η m |
20.5% |
20.7% |
20.9% |
21.0% |
21.2% |
|
Measuring tolerance |
±3% |
||||
|
STC |
Irrdiance 1000W/m2, Cell Temperature 25ºC, Air Mass AM1.5 |
||||
Electrical characteristics with di erent power bin (reference to 10% Irradiance ratio)
|
Total Equivalent power -PMAX |
573Wp |
578Wp |
583Wp |
589Wp |
594Wp |
|
Maximum Power Voltage-VMPP |
31.2V |
31.4V |
31.6V |
31.8V |
32.0V |
|
Maximum Power Current-IMPP |
18.36A |
18.41A |
18.45A |
18.50A |
18.56A |
|
Open Circuit Voltage-VOC |
37.5V |
37.7V |
37.9V |
38.1V |
38.3V |
|
Short Circuit Current-ISC |
19.52A |
19.58A |
19.63A |
19.68A |
19.72A |
|
Irradiance ratio |
10% |
||||
|
Power Bifaciality |
70±5% |
||||
Electrical Data (NOCT)
|
Total Equivalent power -PMAX |
405Wp |
409Wp |
413Wp |
416Wp |
420Wp |
|
Maximum Power Voltage-VMPP |
29.0V |
29.2V |
29.4V |
29.5V |
29.7V |
|
Maximum Power Current-IMPP |
13.97A |
14.02A |
14.08A |
14.10A |
14.14A |
|
Open Circuit Voltage-VOC |
35.5V |
35.5V |
35.7V |
35.9V |
36.1V |
|
Short Circuit Current-ISC |
14.70A |
14.75A |
14.79A |
14.82A |
14.85A |
|
NOCT |
Irradiance at 800W/m2, Ambient Temperature 20°C, Wind Speed 1m/s |
||||
Performance Parameters
|
Temperature Ratings |
NOCT(Nominal Operating Cell Temperature) |
43°C (±2°C) |
|
Temperature Coe cient of PMAX |
- 0.34%/°C |
|
|
Temperature Coe cient of VOC |
- 0.25%/°C |
|
|
Temperature Coe cient of ISC |
0.04%/°C |
|
|
Maximum Ratings |
Operational Temperature |
-40~+85ºC |
|
Maximum System Voltage |
1500V DC (IEC) |
|
|
Max Series Fuse Rating |
35 A |
|
|
Packaging Configuration |
Modules per box |
31 pieces |
|
Modules per 40' container |
527 pieces |
|
|
Warranty |
12 year Product Workmanship Warranty |
|
|
30 year Power Warranty |
||
|
2% rst year degradation |
||
|
0.45% Annual Power Attenuation |
||
Application Scenarios
Trina 555W Solar Panels are innovative, high-performance panels that are designed to provide reliable and efficient energy output for a wide range of applications. Here are three major scenarios where Trina 555W solar panels could be used:
1. Large-scale Solar Projects: With its high efficiency and low light-induced degradation, Trina 555W solar panels are ideal for large-scale solar projects. These panels can be used to power commercial buildings, industrial facilities, and even large cities, reducing reliance on traditional power sources and helping to reduce carbon emissions.
2. Residential Solar Installations: Trina 555W solar panels are also perfect for residential solar installations. These panels can be installed on rooftops or in yards to provide homes with reliable and affordable energy. Trina solar panels are also known for their durability and longevity, which means homeowners can expect many years of reliable performance.
3. Off-Grid Applications: Trina 555W solar panels are also useful in off-grid applications such as remote homes, cabins, and RVs. These panels can be used to power lights, appliances, and other devices, making them an essential part of any off-grid power system. With Trina solar panels, people can enjoy the modern conveniences of electricity even in the most remote locations.
Brand Cooperation
Jingsun is thrilled to announce our long-term strategic partnership with several top-tier solar companies including Trina Solar, Jinko Solar, Longi, JA and more. We are proud to work alongside these cutting-edge solar innovators to drive sustainable solutions and support the global shift towards renewable energy.
Through this powerful collaboration, Jingsun is able to offer our customers access to the most advanced solar technologies, helping to accelerate their transition towards more environmentally conscious energy practices. Our partnerships with these industry leaders ensure that we are at the forefront of solar advancements and able to bring these new technologies to benefit our clients.
At Jingsun, we are committed to a sustainable future for our planet and for future generations. Our collaboration with Trina Solar, Jinko Solar, Longi, JA and other prominent solar companies allows us to amplify our efforts and make an even greater impact. We look forward to working together to provide our customers with the highest quality solar products and services, paving the way towards a brighter tomorrow.
FAQ
Q: What is Trina Solar? What is unique about their 555W solar panels?
Q: How much power can a 555W solar panel generate?
Q: What is the lifespan of a Trina Solar 555W solar panel?
Q: Can I install a Trina Solar 555W solar panel myself?
Q: How much does a Trina Solar 555W solar panel cost?
