Product Advantages

Low Power Temperature Coefficient: The Risen 540W solar panel exhibits low power temperature coefficient, which means that its energy production will not be affected significantly by high temperatures. This makes it a reliable choice even in hot climates.
Excellent Anti-PID Performance: The Risen 540W solar panel is designed to resist Potential-Induced Degradation (PID). This is a process that can reduce the output of a solar panel in certain conditions. The anti-PID performance of the Risen 540W panel ensures that its energy production remains stable and reliable over the long-term.

product-1200-318

Dual Stage 100% EL Inspection: The Risen 540W solar panel undergoes a rigorous dual-stage 100% EL (Electroluminescence) inspection process. This ensures that only the highest quality panels are delivered to customers. The EL inspection process helps detect any potential issues with the panel's cells, such as cracks or defects, and fixes them before the panels are shipped.
High Efficiency: The Risen 540W solar panel has a high efficiency rate, which means that it can convert more sunlight into usable energy. This makes it an excellent choice for those with limited space for solar panels or for people looking to maximize their energy production.
Environmentally Friendly: The Risen 540W solar panel is a clean, renewable energy source that does not emit greenhouse gases or contribute to air pollution. By using Risen solar panels, individuals and organizations can make a positive impact on the environment while powering their homes or businesses.

product-1200-292

Engineering Drawing (mm)

product-1200-566

Mechanical Data

Solar Cells	Monocrystalline
Cell Configuration	110 cells (5×11+5×11)
Module Dimensions	2384×1096×30mm
Weight	30.5kg
Superstrate	High Transmission, Low Iron, Tempered ARC Glass
Substrate	White Back-sheet
Frame	High strength alloy steel, Black
J-Box	Potted, IP68, 1500VDC, 3 Schottky bypass diodes
Cables	4.0mm² , Positive(+)350mm, Negative(-)230mm (Connector Included )
Connector	Risen Twinsel PV-SY02, IP68

product-1200-451

Electrical Parameters At STC

Model Number	RSM110-8-535M	RSM110-8-540M	RSM110-8-545M	RSM110-8-550M	RSM110-8-555M	RSM110-8-560M
Rated Power in Watts-Pmax	535W	540W	545W	550W	555W	560W
Open Circuit Voltage-Voc	37.58V	37.78V	38.02V	38.24V	38.46V	38.68V
Short Circuit Current-Isc	18.13A	18.18A	18.23A	18.28A	18.33A	18.38A
Maximum Power Voltage-Vmpp	31.26V	31.46V	31.66V	31.86V	32.06V	32.26V
Maximum Power Current-Impp	17.12A	17.17A	17.22A	17.27A	17.32A	17.37A
Module Efficiency (%)	20.5%	20.7%	20.9%	21.0%	21.2%	21.4%
STC	Irradiance 1000 W/m², Cell Temperature 25°C, Air Mass AM1.5 according to EN 60904-3

Electrical Parameters At NMOT

Model Number	RSM110-8-535M	RSM110-8-540M	RSM110-8-545M	RSM110-8-550M	RSM110-8-555M	RSM110-8-560M
Maximum Power-Pmax	405.3W	409.0W	412.8W	416.7W	420.5W	424.3W
Open Circuit Voltage-Voc	34.95V	35.14V	35.36V	35.56V	35.77V	35.97V
Short Circuit Current-Isc	14.87A	14.91A	14.95A	14.99A	15.03A	15.07A
Maximum Power Voltage-Vmpp	39.01V	39.19V	39.38V	39.57V	39.75V	39.94V
Maximum Power Current-Impp	13.97A	14.01A	14.05A	14.09A	14.13A	14.17A
NMOT	Irradiance at 800 W/m², Ambient Temperature 20°C, Wind Speed 1 m/s

product-1200-397

Temperature & Maximum Ratings

Nominal Module Operating Temperature (NMOT)	44°C±2°C
Temperature Coefficient of Voc	-0.25%/°C
Temperature Coefficient of Isc	0.04%/°C
Temperature Coefficient of Pmax	-0.34%/°C
Operational Temperature	-40°C~+85°C
Maximum System Voltage	1500VDC
Max Series Fuse Rating	30A
Limiting Reverse Current	30A

Brand Cooperation

We are thrilled to announce our deep collaboration with leading companies in the solar energy industry. At Jingsun, we are committed to advancing the development and use of clean, renewable energy. This partnership allows us to work with like-minded organizations to create innovative solutions that will benefit both our businesses and the environment.

Through this collaboration, we have gained access to cutting-edge technologies and expertise that will enable us to produce high-quality solar panels and energy storage systems. In turn, our partners have access to our advanced manufacturing facilities and highly-trained workforce.

Together, we are committed to driving down the cost of solar energy, expanding its reach across the globe, and creating a sustainable future for generations to come. With our shared vision and expertise, we are confident that this collaboration will bring about positive change in the solar energy industry.

As we continue to work closely together, we look forward to pushing the boundaries of innovation and bringing about a cleaner, healthier planet through the use of solar energy.

product-1200-298

FAQ

Q: What are the benefits of Risen 540W solar panels?

A: Risen 540W solar panels are known for their efficiency and longevity. They are designed to produce high amounts of electricity using minimal space and are built to withstand extreme weather conditions. The panels are also environmentally friendly, with a low carbon footprint, helping reduce the carbon emissions of households and businesses.

Q: How efficient are Risen 540W solar panels?

A: Risen 540W solar panels are considered highly efficient, with a conversion rate of up to 21%. This means that they can transform up to 21% of the available sunlight into usable electricity, making them a popular choice for both residential and commercial spaces.

Q: How long do Risen 540W solar panels last?

A: Risen 540W solar panels are built to last for decades, with an average lifespan of 25 years or more. The panels are equipped with a robust and durable frame and tempered glass, ensuring high resistance to weather and potential damage.

Q: How much energy can Risen 540W solar panels produce?

A: The amount of energy that Risen 540W solar panels can produce depends on several factors, such as geographical location, time of year, and weather conditions. However, on average, a 540W solar panel can produce up to 2000 kWh of electricity per year, which can significantly reduce energy bills and carbon footprints.

Q: Is Risen 540W solar panel a good investment?

A: Yes, investing in Risen 540W solar panels is a good investment choice. The panels are designed to provide long-term, consistent energy production, which can offset power costs and potentially increase property values. Additionally, installing solar panels can help individuals and businesses become more energy independent, reducing their reliance on traditional energy sources and contributing to a cleaner, healthier environment.
