Product Advantages
- High Efficiency: The Risen 405W solar panel is designed with advanced PERC technology, which enables the panel to achieve a high efficiency rate of up to 21%. This means that the panel is able to convert more sunlight into usable energy, resulting in higher energy yields.
- High Durability: The Risen 405W solar panel is constructed with high-quality materials that are designed to withstand harsh weather conditions. The panel is made with tempered glass, which is both scratch-resistant and impact-resistant, making it highly durable.
- Easy Installation: The Risen 405W solar panel is designed for easy installation, with a simple mounting system that requires minimal effort. The panel is also lightweight, making it easy to transport and handle.
- Cost-Effective: The Risen 405W solar panel is an affordable solution for generating clean and renewable energy. The panel has a relatively low cost per watt, which makes it a cost-effective option for residential and commercial solar installations.
- Long Lifespan: The Risen 405W solar panel has a long lifespan, with a warranty of up to 25 years. This means that the panel will continue to produce high-quality energy for decades to come, providing a reliable and sustainable source of energy for your home or business.
Engineering Drawing (mm)
Mechanical Data
|
Solar Cells |
Monocrystalline |
|
Cell Configuration |
120 cells (5×12+5×12) |
|
Module Dimensions |
1754×1096×30mm |
|
Weight |
22kg |
|
Superstrate |
High Transmission, Low Iron, Tempered ARC Glass |
|
Substrate |
White Back-sheet |
|
Frame |
High strength alloy steel, Black |
|
J-Box |
Potted, IP68, 1500VDC, 3 Schottky bypass diodes |
|
Cables |
4.0mm² , Positive(+)350mm, Negative(-)230mm (Connector Included ) |
|
Connector |
Risen Twinsel PV-SY02, IP68 |
Electrical Parameters At STC
|
Model Number |
RSM40-8-395M |
RSM40-8-400M |
RSM40-8-405M |
RSM40-8-410M |
RSM40-8-415M |
RSM40-8-420M |
|
Rated Power in Watts-Pmax |
395W |
400W |
405W |
410W |
415W |
420W |
|
Open Circuit Voltage-Voc |
41.00V |
41.30V |
41.60V |
41.90V |
42.20V |
42.49V |
|
Short Circuit Current-Isc |
12.27A |
12.34A |
12.40A |
12.47A |
12.53A |
12.59A |
|
Maximum Power Voltage-Vmpp |
34.14V |
34.39V |
34.64V |
34.89V |
35.14V |
35.38V |
|
Maximum Power Current-Impp |
11.58A |
11.64A |
11.70A |
11.76A |
11.82A |
11.88A |
|
Module Efficiency (%) |
20.5% |
20.8% |
21.1% |
21.3% |
21.6% |
21.8% |
|
STC |
Irradiance 1000 W/m², Cell Temperature 25°C, Air Mass AM1.5 according to EN 60904-3 |
|||||
Electrical Parameters At NMOT
|
Model Number |
RSM40-8-395M |
RSM40-8-400M |
RSM40-8-405M |
RSM40-8-410M |
RSM40-8-415M |
RSM40-8-420M |
|
Maximum Power-Pmax |
299.4W |
303.1W |
306.9W |
310.7W |
314.5W |
318.3W |
|
Open Circuit Voltage-Voc |
38.13V |
38.41V |
38.69V |
38.97V |
39.25V |
39.52V |
|
Short Circuit Current-Isc |
10.07A |
10.12A |
10.17A |
10.22A |
10.27A |
10.33A |
|
Maximum Power Voltage-Vmpp |
31.68V |
31.91V |
32.15V |
32.38V |
32.61V |
32.83V |
|
Maximum Power Current-Impp |
9.45A |
9.50A |
9.55A |
9.60A |
9.65A |
9.69A |
|
NMOT |
Irradiance at 800 W/m², Ambient Temperature 20°C, Wind Speed 1 m/s |
|||||
Temperature & Maximum Ratings
|
Nominal Module Operating Temperature (NMOT) |
44°C±2°C |
|
Temperature Coefficient of Voc |
-0.25%/°C |
|
Temperature Coefficient of Isc |
0.04%/°C |
|
Temperature Coefficient of Pmax |
-0.34%/°C |
|
Operational Temperature |
-40°C~+85°C |
|
Maximum System Voltage |
1500VDC |
|
Max Series Fuse Rating |
20A |
|
Limiting Reverse Current |
20A |
