Product Advantages
- Lower LCOE (Levelized Cost of Energy): The Canadian 400W full black solar panel is designed with highly efficient solar cells that convert more sunlight into electricity, resulting in higher energy production and lower LCOE. This means that the cost per unit of energy produced is lower, making it a more cost-effective option.
- System Cost Savings: The full black design of the Canadian 400W solar panel not only gives it a sleek and attractive appearance, but also reduces the cost of installation by eliminating the need for complex racking and mounting systems. This can translate into significant cost savings for the homeowner or business owner.
- Better Shading Tolerance: The Canadian 400W solar panel is designed with innovative bypass diodes that can minimize the effects of partial shading on the system, ensuring that energy production is not affected by shading caused by trees, buildings or other obstacles.
- Comprehensive LID/LeTID Mitigation Technology: The Canadian 400W solar panel is designed to withstand the effects of Light Induced Degradation (LID) and Light and Elevated Temperature Induced Degradation (LeTID) which are common causes of reduced energy production in solar panels over time. This means the panels will last longer and require less maintenance.
- Environmentally Friendly: The Canadian 400W full black solar panel is made from high-quality materials and uses advanced manufacturing techniques that minimize waste and reduce carbon emissions. This makes it an environmentally sustainable energy solution that can help reduce the carbon footprint of any home or business that uses it as a primary source of energy.
Engineering Drawing (mm)
Mechanical Data
Cell Type |
Mono-crystalline |
Cell Arrangement |
108 [2 X (9 X 6) ] |
Dimensions |
1722 ˣ 1134 ˣ 30 mm (67.8 ˣ 44.6 ˣ 1.18 in) |
Weight |
21.3 kg (47.0 lbs) |
Front Cover |
3.2 mm tempered glass with anti-reflective coating |
Frame |
Anodized aluminium alloy |
J-Box |
IP68, 3 bypass diodes |
Cable |
4 mm² (IEC), 12 AWG (UL) |
Connector |
T6 or MC4 or MC4-EVO2 or MC4-EVO2A |
Cable Length (Including Connector) |
Portrait: 350 mm (16.1 in) (+) / 250 mm (11.4 in) (-); landscape: 1100 mm (43.3 in) |
Per Pallet |
36 pieces |
Electrical Parameters At STC
CS6R |
380MS |
385MS |
390MS |
395MS |
400MS |
405MS |
Max Power (Pmax) |
380W |
385W |
390W |
395W |
400W |
405W |
Operating Voltage (Vmp) |
30.0V |
30.2V |
30.4V |
30.6V |
30.8V |
31.0V |
Operating Current (Imp) |
12.69A |
12.77A |
12.84A |
12.91A |
12.99A |
13.07A |
Open Circuit Voltage (Voc) |
36.0V |
36.2V |
36.4V |
36.6V |
36.8V |
37.0V |
Short Circuit Current (Isc) |
13.55A |
13.63A |
13.70A |
13.77A |
13.85A |
13.93A |
Module Efficiency |
19.5% |
19.7% |
20.0% |
20.2% |
20.5% |
20.7% |
Operating Temperature |
-40°C ~ +85°C |
|||||
Max. System Voltage |
1500V (IEC/UL) or 1000V (IEC/UL) |
|||||
Module Fire Performance |
TYPE 1 (UL 61730 1500V) or TYPE 2 (UL 61730 1000V) or CLASS C (IEC 61730) |
|||||
Max. Series Fuse Rating |
25 A |
|||||
Application Classification |
Class A |
|||||
Power Tolerance |
0 ~ + 10 W |
Electrical Parameters At NOCT
CS6R |
380MS |
385MS |
390MS |
395MS |
400MS |
405MS |
Max Power (Pmax) |
284W |
288W |
291W |
295W |
299W |
303W |
Operating Voltage (Vmp) |
28.1V |
28.3V |
28.4V |
28.6V |
28.8V |
29.0V |
Operating Current (Imp) |
10.12A |
10.19A |
10.26A |
10.33A |
10.39A |
10.45A |
Open Circuit Voltage (Voc) |
33.9V |
34.1V |
34.2V |
34.4V |
34.6V |
34.7V |
Short Circuit Current (Isc) |
10.91A |
10.98A |
11.05A |
11.11A |
11.17A |
11.23A |
Temperature Coefficient (Pmax) |
-0.34 % / °C |
|||||
Temperature Coefficient (Voc) |
-0.26 % / °C |
|||||
Temperature Coefficient (Isc) |
0.05 % / °C |
|||||
Operating Temperature |
42 ± 3°C |
Brand Cooperation
Jingsun is proud to announce its collaboration with several leading solar companies in the industry. Our partnership with these top-tier brands ensures that we are able to deliver the highest quality solar products to our customers. By joining forces, we have combined our expertise, resources, and technologies to provide innovative solutions for a sustainable future. This collaboration enables us to offer an extensive range of solar panels, inverters, and batteries, along with complete solar kits for homes, businesses, and large-scale projects. Plus, we are committed to providing outstanding customer service and support to ensure our customers get the most out of their solar systems. With this landmark partnership, we are excited about the opportunities to help more people embrace solar energy and reduce their carbon footprint.
FAQ
Q: What is the power output of the Canadian 400w all-black solar panel?
Q: What is the efficiency rating of the Canadian 400w all-black solar panel?
Q: What is the durability of the Canadian 400w all-black solar panel?
Q: What is the warranty on the Canadian 400w all-black solar panel?
Q: How can I install the Canadian 400w all-black solar panel?
