Product Advantages
- High-Quality Battery Cells: The Jingsun 48V 50AH Lithium-ion Battery is designed with high-quality battery cells that offer enhanced safety, durability and reliability. The battery cells are manufactured with advanced technology that ensures high performance and efficient energy storage.
- Advanced Control System: The Jingsun 48V 50AH Lithium-ion Battery comes with an advanced control system that offers better control and management of the battery. The control system ensures optimal charging and discharging of the battery, prevents overcharging and over-discharging, and extends the lifespan of the battery.
- Innovative Rack Design: The battery is designed with an innovative rack system that offers reliable and secure mounting. The rack system ensures stability and reduces vibration, which helps to prevent damage to the battery during transport or use.
- Easy to Install: The Jingsun 48V 50AH Lithium-ion Battery is designed for easy installation and integration with different types of equipment. The battery's modular design allows it to be easily installed in various locations, making it ideal for a range of applications.
- Long-Lasting Performance: The Jingsun 48V 50AH Lithium-ion Battery is designed to provide long-lasting performance,The battery's high energy density and low self-discharge rate ensure that it maintains its charge for extended periods, providing reliable power for a wide range of applications.
Product Specification
|
Model |
48V50AH |
|
Capacity |
2.4KWH |
|
Normal Discharging Current |
25A |
|
Max Discharging Current |
50A |
|
Voltage |
40.5-54V DC |
|
Standard Voltage |
48VDC |
|
Charging Current |
50A |
|
Max Charging Voltage |
54V |
|
Suggested DOD Model |
90% |
|
Size(mm) |
484*410*88.5 |
|
Weight |
24.5kg |
|
Humidity |
10-85% |
|
Installation |
Rack mounted or cabinet |
|
IP Rating |
IP20 |
|
Max Number Of Parrallel |
16 |
|
Warranty |
5years |
|
Communication |
4GWiFi/blue tooth/4Goptional) |
|
Monitor |
WIFI |
|
Battery Protection |
Over Current/Over Voltage/Short Circuit/Low Voltage/High Temperature |
Customized Plan
- Customizable Size and Shape: Jingsun's rack-mounted lithium-ion batteries are customizable in size and shape to fit the specific requirements of each application. This allows for maximum use of available space and increased functionality.
- Tailor-Made Voltage and Capacity: Jingsun can create customized lithium-ion battery solutions with unique voltage and capacity requirements to meet the specific needs of different applications. This ensures optimal performance and efficiency.
- Customizable BMS Settings: Jingsun can provide a customized battery management system (BMS) to ensure that the battery operates optimally and safely. This includes customizing the charging and discharging rates and protection mechanisms to protect against overcharging and thermal runaway.
- Enhanced Performance: Jingsun can create custom battery solutions with high discharge rates that allow for quick and efficient energy transfer. This is particularly important in applications that require rapid energy storage and release, such as in electric vehicles or renewable energy storage systems.
- Environmentally Friendly: Jingsun uses non-toxic and environmentally friendly materials in their lithium-ion batteries, ensuring that their customized solutions are safe for use in any application. This supports the growing demand for sustainable energy solutions.
Pay Attention
- Recommended Maximum Capacity: The Jingsun rack-mounted Lithium-ion Battery has a recommended maximum capacity, and it is important not to exceed this limit. Operating the battery beyond its recommended maximum capacity can damage both the battery and the equipment it is powering.
- Proper Ventilation: Adequate ventilation is important when using the Jingsun rack-mounted Lithium-ion Battery. The battery can generate heat during operation, and proper ventilation ensures that the temperature remains within safe limits.
- Regular Maintenance: Regular maintenance is crucial to ensure the long-term performance of the Jingsun rack-mounted Lithium-ion Battery. It is recommended to follow the manufacturer's instructions for maintenance and to schedule regular maintenance checks to avoid unexpected failures.
- Proper Disposal: Proper disposal of Lithium-ion batteries is important for environmental safety. When the Jingsun rack-mounted Lithium-ion Battery has reached the end of its useful life, it should be recycled or disposed of in accordance with local regulations.
- Safety Precautions: Lithium-ion batteries should be handled with care, and appropriate safety precautions should be taken when installing or using the Jingsun rack-mounted Lithium-ion Battery. It is recommended to read the user manual and follow the recommended safety procedures to prevent accidents and injury.
Applications
Scalability
Rack-mounted Lithium-ion batteries are highly scalable and can be easily expanded to meet the energy demands of a business or home. This makes them an excellent choice for both large-scale commercial applications and smaller residential projects. Additionally, they can be integrated with a variety of solar power systems, including grid-tied and off-grid systems.
Rack-mounted Lithium-ion batteries are highly scalable and can be easily expanded to meet the energy demands of a business or home. This makes them an excellent choice for both large-scale commercial applications and smaller residential projects. Additionally, they can be integrated with a variety of solar power systems, including grid-tied and off-grid systems.
High Efficiency
Rack-mounted Lithium-ion batteries are a popular choice for solar energy applications due to their high efficiency. They are capable of storing a significant amount of energy and can be charged quickly, allowing for a seamless integration with solar panels.
Rack-mounted Lithium-ion batteries are a popular choice for solar energy applications due to their high efficiency. They are capable of storing a significant amount of energy and can be charged quickly, allowing for a seamless integration with solar panels.
FAQ
Q: What is a rack-mounted Lithium-ion Battery for solar power?
A: A rack-mounted Lithium-ion Battery for solar power is a type of energy storage solution that is specifically designed for use with solar panels. It is made to be installed in a rack system, making it easy to integrate with existing solar arrays.
Q: How does a rack-mounted Lithium-ion Battery work with solar power?
A: When solar panels generate energy, it is stored in the rack-mounted battery for later use. The battery stores this energy as Direct Current (DC), and when the power is needed, it is converted into Alternating Current (AC) and distributed to the grid.
Q: What are the benefits of using a rack-mounted Lithium-ion Battery for solar power?
A: One major benefit of using a rack-mounted Lithium-ion Battery for solar power is that it allows for greater energy control and independence. This is because it allows users to store excess energy for later use, rather than relying on immediate consumption. Additionally, this type of battery can help reduce energy costs and increase the value of the solar panel system.
